KT-txz PVC Domestic Industrial Equipment Safety Advanced Edge Customization Safety Anti Collision Compression Flexible Strip Switch Sensor
safety sensors safety edge switch elevator safety edge safety edge sensor safety edge agv collision AGV switch anti collision switch
Installation method: using bolt track method, screws can slide freely (M8/M6 screws)
Bottom composition: The bottom is made of aluminum extrusion material, ensuring lightness and precision
Outer skin color: You can use either black or yellow, or both colors
Outer skin: Vinyl leather (sewing process)
Cushion material: polyurethane foam
Bottom plate: Aluminum extruded material
Wire: 4-wire/customized; Standard length 500mm
- Overview
- Display
- Recommended Products
What benefits can we bring to our customers?
1.We are a manufacturer that can offer customers preferential prices and have an absolute price advantage
2. We can create customized drawings for customers free of charge until they are satisfied.
3. We can provide comprehensive online guidance to solve customers' practical problems.
4. Our company can provide the most favorable, efficient, and customer friendly transportation solutions.
5. Our company accepts various payment methods, such as VTB, Visa, Paypal, China UnionPay, etc
What advantages do we have?
1.We have nearly 20 years of production experience and are well versed in product parameters, able to solve any difficult problems for customers.
2. We have the most advanced equipment and instruments to ensure the accuracy and stability of product data.
3. We have 50 professional technical experts and teams, constantly optimizing and updating our products.
4.Our company has over 200 staff members, each with clear job responsibilities to ensure timely delivery of products.
Specifications:
| Property | Technical Parameters |
| Activation distance | 9mm (at 10mm/S) |
| Environmental temperature | -20 degrees+55 degrees |
| Connection method | 2-core plug or 2-core cable (2m/5m) |
| Response time | within 30ms |
| Service life | 100000 cycles |
| Outer skin | vinyl leather, splash guard Heat proof、 Aluminum leather |
| Buffer material | polyurethane foam, foam rubber (selected according to the use) |
| Bottom plate | iron plate, plywood, stainless steel plate |
| Installation screws | M8/M6/customized |
| Workload | approximately 40N/customized |
| Wire | VFF (ethylene parallel wire)/customized |
| Wire length | 500mm/customized |
Quick Detail:
Rebound rubber strip when encountering obstacles, safety edge switch, pressure-sensitive switch.
The safety edge and safety buffer are flexible and bendable strips that can be fixed on the edges of moving parts such as machine tool workbenches and electric doors that pose risks of compression and shearing.
Description:
The safety edge contact strip is composed of two elements made of conductive silicone, separated by a specific distance. The end of the contact strip can be connected to different end pieces depending on its application purpose. After inserting it into the rubber sleeve and connecting it to the switch, all components form a complete system. The safety edge can be easily and quickly assembled by users themselves. Due to the various lengths available in our production, we are very flexible in terms of assembly.
Widely used in AGV cars, welding robots, packaging machinery, automation equipment, automatic balancing doors, electric doors, etc.
Competitive Advantage:
The safe edge contact needs to be combined with the controller to form a flexible and universal emergency stop system. When using this system, the robot operator and installer must be able to easily and conveniently stop the dragging device. A complete safety edge includes an aluminum guide rail - a safety contact and a built-in sensing signal strip (contact strip). The special shape of the safety edge (rubber side) can protect the safety contact belt from damage and allow the impact angle of the safety edge to exceed 90 °.
Product actual photo:
Factory actual shooting:
Exhibition Display：
